| 安裝環境Installation environment | 室內或室外Indoor or outdoor | |
| 安裝方式Installation | 無基坑安裝, 高80MMNo foundation pit installation, high 80MM | |
| 有基坑安裝，深80MMFoundation pit installation, deep 80MM | ||
| 安裝空間installation space | 1300MM X 2000MM | Can be customized |
| 外形尺寸outline dimension | 1250MM X 1920MM(含自動翻板 automatic flap) | Can be customized |
| 平臺尺寸Platform size | 900MM? X 1426MM?? | Can be customized |
| 最大高度maximum altitude | 最大13米Maximum 13m | |
| 出入方向?? Access directions | 180°貫通/ 90°/或原進原出?? 180°through /90°/ or original in / out | |
| 控制電源 Control Source | 220V/AC | |
| 電機功率 Motor Power | 1.1KW或1.5KW? 220V/AC??? 1.1KWor1.5KW? 220V/AC | |
| 電???? 源Power Supply | 220V/50HZ/25A | |
| 液壓主機Hydraulic Host | 攀杰公司原裝產品，成套液壓系統 Climb jade products complete hydraulic system | |
| 驅動方式Driving mode | 液壓驅動hydraulic pressure | |
| 運行方式Running Mode: | 點動控制/或自動Jogging Control or automatic control | |
| 運行速度running speed | 80-120MM/秒100MM/sec | |
| 升降控制Lifting Control: | 采用“翹板自復位開關操作運行”Adopts “Operation by self-resetting switch of wane | |
| 過載保護Overload Protection | 過電流繼電器控制Over-current relay control | |
| 護板形式 guard plate form | 90°或180°，互換配置?? 90°or 180°switch configuration | |
| 升降平臺底板 the platform floor | 花紋鋼板（靜電噴塑）plate(electrostatic pensu) | |
| 整機顏色Machine color | 標準色：白色（可選）Standard Color: White (optional) | |
| 機箱面板Case Panel | 鋁合金板（靜 電 噴 塑）aluminium alloy plate(electrostatic pensu) | |
| 自動翻板Automatic flap | 75° | |
| 最大承重Maximum load bearing | 250KG/350KG | |
| 設備噪音noise | 60dB （液壓系統內置 標準）Hydraulic system built-in Standards) | |
| 工作溫度working temperature | -10C°/ +60C° | |
| 外控裝置Extrocontrol Device | 外呼盒分別安置于設備上、下停層附近墻面，也可選用遙控器 The calling box shall be installed in the neighboring wall of the upper/lower layer of the equipment and remote controller shall also be used for options |
|
| 安全裝置 safety device |
* 手動應急下降? Manual emergency descent * 平臺主控面板優先 Platform master panel preferred * 緊急停止按鈕? Emergency stop button * 層門與設備聯動控制Layer and equipment linkage control * 防墜落機械裝置 anti-fall mechanical device * 安全觸板 security contact * 電控系統防過流過載保護 Electronic control system to prevent overcurrentoverload protection * 平臺超重保護? Platform Overweight Protection * 液壓油路防爆閥Hydraulic oil circuit explosion-proof valve |
|
